IK Multimedia AmpliTube X-DRIVE Distortion Pedal Overview:

It’s time to break free

Bring your perfect studio guitar sound onstage with the new AmpliTube X-DRIVE distortion pedal. This boutique pedal features 16 all-new overdrive and distortion effects leveraging IK’s latest AmpliTube technologies accompanied by an exclusive virtual X-GEAR version of the exact same effects. Use the virtual version with AmpliTube 5 (SE version included) to record and tweak settings and save as presets on your X-DRIVE pedal for world-class tone anywhere.

Features

• Breakthrough software and hardware integration for guitarists
• State-of-the-art DSP in a road-worthy anodized aluminum chassis
• 16 different algorithms 50 factory presets (300 storable presets)
• Distortion overdrive fuzz compressor and more + cab emulation
• Includes exclusive virtual X-DRIVE version for use in AmpliTube 5
• USB port for preset management and use as a recording interface
• Full MIDI implementation including control over AmpliTube 5
• Designed and made in Italy for a lifetime of playing and gigging

Best-in-show DSP

AmpliTube X-DRIVE leverages IK’s latest technologies for hyper-realistic emulations of real-world gear. The state-of-the-art DSP onboard offers 16 high-end algorithms while a special X-MODE opens additional signal boosting features. Using 192kHz internal processing with 4x oversampling X-DRIVE delivers amazing clarity to the stage with the realism and response that users love about AmpliTube 5.

Hardware that stands out

For AmpliTube X-DRIVE we went all out to guarantee your tone stays as pure and pristine as possible no matter how simple or sophisticated your signal chain becomes.

• Ultra-low noise 24-bit/192kHz converters for class-leading sound quality
• 5 Hz–24 kHz frequency response to capture the full scope of your guitar’s sound
• 123 dB dynamic range provides whisper-quiet operation at any gain setting
• Selectable true or soft bypass for maximum control

Industry-leading integration

AmpliTube X-DRIVE includes a matching virtual version for Mac/PC and a copy of AmpliTube 5 SE. Open any version of AmpliTube 5 and you’ll find your virtual X-DRIVE pedal available as a stomp for use within the program. Adjust any of your pedal settings with the convenience of AmpliTube’s award-winning workflow and save them as presets. The X-GEAR Librarian lets you move presets between X-GEAR pedals and AmpliTube and easily reorganize them on the hardware pedal. You can store up to 300 presets per pedal.

All-in-one recording

With AmpliTube X-DRIVE there’s no need for any other gear when it comes to recording guitar. We’ve put a USB audio interface and some must-have recording features right onboard.

• 5Hz to 24kHz frequency response to record the full range of your guitar or bass
• Versatile routing options let you send the wet and/or dry signals to your DAW
• Stereo out for monitoring sound between the X-DRIVE pedal and your computer
• Full MIDI implementation to map control of AmpliTube and/or any compatible DAW

From soundcheck to final encore

When it’s time to play out AmpliTube X-DRIVE holds everything you need to perform at your best. In fact you can even leave your amp and cab at home if you want to.

• Fast intuitive interface and control knobs to tweak your sound on the fly
• High-contrast LED display keeps you informed on everything indoors and out
• Expression pedal input adds additional control over any parameter you choose
• Full MIDI implementation is built-in for even the most complex setups
• 5 cabinet impulse responses and a CAB SIM out to connect directly to the PA

Specifications

• Breakthrough software and hardware integration for guitarists
• State-of-the-art DSP in a road-worthy anodized aluminum chassis
• 16 different algorithms 50 factory presets (300 storable presets)
• Distortion overdrive fuzz compressor and more + cab emulation
• Includes exclusive virtual X-DRIVE version for use in AmpliTube 5
• USB port for preset management and use as a recording interface
• Full MIDI implementation including control over AmpliTube 5
• Designed and made in Italy for a lifetime of playing and gigging
• Ultra-low noise 24-bit/192kHz converters for class-leading sound quality
• 5 Hz–24 kHz frequency response to capture the full scope of your guitar’s sound
• 123 dB dynamic range provides whisper-quiet operation at any gain setting
• Selectable true or soft bypass for maximum control
• 5Hz to 24kHz frequency response to record the full range of your guitar or bass
• Versatile routing options let you send the wet and/or dry signals to your DAW
• Stereo out for monitoring sound between the X-DRIVE pedal and your computer
• Full MIDI implementation to map control of AmpliTube and/or any compatible DAW
• Fast intuitive interface and control knobs to tweak your sound on the fly
• High-contrast LED display keeps you informed on everything indoors and out
• Expression pedal input adds additional control over any parameter you choose
• Full MIDI implementation is built-in for even the most complex setups
• 5 cabinet impulse responses and a CAB SIM out to connect directly to the PA

Package includes

• X-DRIVE pedal
• USB A-Type to USB B-Type connection cable (1.5m/4.32ft)
• Power Supply Unit
• Plug-in and Preset Librarian serial number

Dimensions

• Size: 17.5cm/6.88" x 14.5cm/5.7" x 5.8cm/2.28"
• Weight: 906g/31.96oz

System Requirements

AmpliTube 5

AmpliTube is a 64-bit application and requires a 64 bit CPU and Operating System.

Mac (64-bits)

Minimal: Intel Core 2 Duo (Intel Core i5 suggested) 4 GB of RAM (8 GB suggested) macOS 10.10 or later. 3 GB of hard drive space.

Requires an OpenGL 2 compatible graphics adapter.

Supported Plug-in formats (64-bit): Audio Units VST 2 VST 3 AAX.

Windows (64-bits)

Minimal: Intel Core 2 Duo or AMD Athlon 64 X2 (Intel Core i5 suggested) 4 GB of RAM (8 GB suggested). Windows 7 or later. 3 GB of hard drive space.

Requires an ASIO compatible sound card.

Requires an OpenGL 2 compatible graphics adapter.

Supported Plug-in formats (64-bit): VST 2 VST 3 AAX.

Internet connection is required as all of the Custom Shop operations are web based.
