Ibanez GRGR330EX RG 6 String Electric Guitar Overview:

A guitar doesn't have to cost a bundle to sound good. The GIO series was developed for players who want Ibanez quality in a more affordable package. Not only do they look and play better than everything else in their price range, but their rigorous inspection, set-up and warranty is the same as Ibanez's more expensive models.





Maple neck
The Maple neck provides stability and bright tonal character.









Purpleheart fretboard
The Purpleheart fretboard emphasizes the beauty and the rich tonal character of this guitar.









Double Locking tremolo
The Double Locking system holds your guitar in tune even under aggressive on-stage abuse.











Mono-unit output jack
The mono-unit output jack is made of solid, durable material and is a single piece to avoid unwanted movement and loosening of the jack, which leads to contact failure or disconnection. This innovation allows for long term playing enjoyment and minimal maintenance.





Specifications:

• neck type: GRGMaple neck
• top/back/body: Poplar body
• fretboard: Bound Purpleheart fretboardReveresed Black Sharktooth inlay
• fret: Medium frets
• number of frets: 24
• bridge: Double Locking bridge
• string space: 10.5mm
• neck pickup: Infinity R (H) neck pickupPassive/Ceramic
• bridge pickup: Infinity R (H) bridge pickupPassive/Ceramic
• factory tuning: 1E,2B,3G,4D,5A,6E
• string gauge: .009/.011/.016/.024/.032/.042
• nut Locking: nut
• hardware color: Black

NECK DIMENSIONS

• Scale : 648mm/25.5"
• a : Width 43mm at NUT
• b : Width 58mm at 24F
• c : Thickness 19.5mm at 1F
• d : Thickness 21.5mm at 12F
• Radius : 400mmR
