Dunlop MXR EG74 Raw Dawg Overdrive Effect Pedal Overview:

A custom circuit this pedal is based on a classic OD famous for its grit and crunch—but we balanced out the midrange and bumped up the gain for a sweeter more natural sound even when cranked. This pedal can be powered by a Dunlop ECB003 9-volt adapter or the DC Brick Iso-Brick and Mini Iso-Brick power supplies (not included).

Specifications

• Input Impedance: > 450 k?
• Output Impedance: < 100 ?
• Noise Floor*: < -100 dBV
• Gain: 21 to 47 dB
• Bypass: True Hardwire
• Current Draw: 6 mA
• Power Requirements: 9V DC (Power Supply not included)
